CARBON LAMINATE ANGLES
|
| Service Temperature
|
Part Number
|
|
350°F
|
#1033
|
|
FIBERGLASS LAMINATE ANGLES |
Service Temperature
|
Part Number
|
|
180°F
|
#1010
|
|
350°F
|
#1030
|
Standard Dimensions:
Carbon
- Thickness: 1/8", 1/4", 3/8"
- Leg Width: 2", 4", 6"
- Length: 8', 12'
Fabrication:
Angles are fabricated by hand laying woven impregnated Graphite or Fiberglass fabric onto a steel mold. Angles are then press cured, trimmed, and post cured.
Finish:
Peel ply on both faces
Features:
- High strength and stiffness
- Very low coefficient of thermal expansion
- Long term stability at ambient and high temperatures
- Typical delivery 3-4 weeks
- Angles can be pre-cut and delivered in kits
Application:
The composite tooling industry uses angles for additional support of eggcrate, truss, and master model substructures.
